High Durability Long Life Linear Bearing with High Rigidity for Precision Motion

1
MOQ
$3.5-$141
Price
High Durability Long Life Linear Bearing with High Rigidity for Precision Motion
Features Gallery Product Description Chat Now
Features
Specifications
Name: Linear Flange Bearing
Type: Linear,linear Motion Slide Ball Bearing
Feature: Anti-friction,Low Noise,Long Life Linear Bearing LM6UU,Long Life,High Quality
Performance: High Speed
Operating Temperature: -20°C To 80°C
Highlight:

high precision linear bearing

,

low friction linear bearing

,

durable linear bearing with warranty
Basic Infomation
Place of Origin: China
Brand Name: SXEGL
Certification: CE/FCC/EPA/ROSH/ISO
Model Number: LM..Luu/LM...CLUU
Payment & Shipping Terms
Packaging Details: Carton
Delivery Time: Small orders usually takes 3-7 days,big order usually 20-35 days, depending on orders quantity and whether are standard size.
Payment Terms: Visa /Mastercard/PayPal/Apple Pay/Google Pay
Supply Ability: All products have passed CE certification and comply with EU RoHS environmental standards
Product Description
High Precision  Low Friction Linear Bearing High Durability
As a core component for precision linear motion, linear bearings have become a rigid demand for high-end equipment due to their outstanding performance. Crafted from high-quality bearing steel or stainless steel, the product undergoes precision machining and heat treatment, boasting a repeat positioning accuracy of ±0.01mm, a rolling friction coefficient as low as 0.001-0.003, and a transmission efficiency exceeding 90%.
With a compact structure, it supports combined radial and axial loads. The high-rigidity design suppresses vibration and deformation, adapting to high-speed operation up to 5m/s, while featuring low noise and energy consumption. Some models are equipped with self-lubricating and sealing structures, enabling dust resistance and high-temperature tolerance, along with a long maintenance cycle. Standardized interfaces ensure excellent interchangeability and easy installation.
Widely applied in automated production lines, CNC machine tools, semiconductor equipment, medical surgical robots, industrial robots, 3D inspection instruments, and intelligent logistics systems, it provides stable and efficient linear transmission solutions for scenarios such as laser processing, wafer handling, and precision assembly, safeguarding the accuracy and service life of equipment.

High Durability Long Life Linear Bearing with High Rigidity for Precision Motion 0

Model Number of ball rows Weight (gf) Inner diameter Outer diameter
 dr Tolerance D Tolerance
LM3LUU 4 3 3 0 7 0
-0.01 -0.013
LM3CLUU 4 3 3 0 7 0
-0.01 -0.013
LM4LUU 4 4 4 0 8 0
-0.01 -0.013
LM4CLUU 4 4 4 0 8 0
-0.01 -0.013
LM5LUU 4 8 5 0 10 0
-0.01 -0.013
LM5CLUU 4 8 5 0 10 0
-0.01 -0.013
LM6LUU 4 16 6 0 12 0
-0.01 -0.013
LM6CLUU 4 16 6 0 12 0
-0.01 -0.013
LM8LUU 4 31 8 0 15 0
-0.01 -0.013
LM8CLUU 4 31 8 0 15 0
-0.01 -0.013
LM10LUU 4 62 10 0 19 0
-0.01 -0.016
LM10CLUU 4 62 10 0 19 0
-0.01 -0.016
LM12LUU 5 80 12 0 21 0
-0.01 -0.016
LM12CLUU 5 80 12 0 21 0
-0.01 -0.016
LM13LUU 5 90 13 0 23 0
-0.01 -0.016
LM13CLUU 5 90 13 0 23 0
-0.01 -0.016
LM16LUU 5 145 16 0 28 0
-0.012 -0.016
LM16CLUU 5 145 16 0 28 0
-0.012 -0.016
LM20LUU 6 180 20 0 32 0
-0.012 -0.019
LM20CLUU 6 180 20 0 32 0
-0.012 -0.019
LM25LUU 6 440 25 0 40 0
-0.012 -0.019
LM25CLUU 6 440 25 0 40 0
-0.012 -0.019
LM30LUU 6 580 30 0 45 0
-0.012 -0.019
LM30CLUU 6 580 30 0 45 0
-0.012 -0.019
LM35LUU 6 795 35 0 52 0
-0.012 -0.022
LM35CLUU 6 795 35 0 52 0
-0.012 -0.022
LM40LUU 6 1170 40 0 60 0
-0.012 -0.022
LM40CLUU 6 1170 40 0 60 0
-0.012 -0.022
LM50LUU 6 2100 50 0 80 0
-0.02 -0.025
LM50CLUU 6 2100 50 0 80 0
-0.02 -0.025
LM60LUU 6 3500 60 0 90 0
-0.02 -0.025
LM60CLUU 6 3500 60 0 90 0
-0.02 -0.025
