Name: Corrosion Resistant KR Bearing Compact Bolt Type Needle Roller Bearing Higher Carrying Capacity
Brand: SXEGL Intelligent Technology Co., Ltd.
SKU: GE-E
Price: 5.50 USD
Availability: InStock

Features Gallery Product Description Request A Quote

Features

Specifications

Product Name: Bolt Type Needle Roller Bearing

Material: S55C

Applicable Industries: Mechanical

Performance: Long Life Large Carrying Capacity Corrosion Resistance

Color: Silver, Black

Length: Customized

Nut Type: Single Nut$ Double Nut

Structure: CNC Components

Core Components: Engine, Bearing, Motor, Pressure Vessel

Highlight:

Corrosion Resistant KR Bearing

KR Bearing Compact

Compact Bolt Type Needle Roller Bearing

Basic Infomation

Place of Origin: China

Brand Name: SXEGL

Certification: CE/FCC/EPA/ROSH/ISO

Model Number: GE-E

Payment & Shipping Terms

Packaging Details: Carton

Delivery Time: Small orders usually takes 3-7 days,big order usually 20-35 days, depending on orders quantity and whether are standard size.

Payment Terms: Visa /Mastercard/PayPal/Apple Pay/Google Pay

Supply Ability: All products have passed CE certification and comply with EU RoHS environmental standards

Gallery

Corrosion Resistant KR Bearing Compact Bolt Type Needle Roller Bearing Higher Carrying Capacity

Product Description

Compact Structure KR Bolt Type Needle Roller Bearings Higher Carrying Capacity

SEXGL rod end bearings:KR bolt type roller needle bearing is a special structure rolling bearing.

Compact structure: The bolt function is combined with the roller needle bearing, which takes up little space and can effectively save installation space.
High load capacity: The design of the needle bearing enables it to withstand large radial loads and is suitable for heavy-duty conditions.

Company advantages

OEM factory, high quality, precision processing, assembly line assembly, 100% quality control process, sufficient inventory, fast and safe transportation.

Corrosion Resistant KR Bearing Compact Bolt Type Needle Roller Bearing Higher Carrying Capacity 0

Type		Dimension (mm)												Basic load rating		Limits of speed	Mass	JJ	IKO Designation
		D*	C	D₁	G	G₁	Bmax	B₁max	B₂	B₃	C₁	rsmin		動負荷 C	靜負荷 Co
KR13	KRV13	13	9	5	M5×0.8	7	10	23	13	0.5	0.3	0.25	280	180	29000	16	NAKD13	NAKD13V	CF5
KR16	KRV16	16	11	6	M6×1	8	12.2	28.2	16	0.6	0.3	0.25	270	170	25000	18	NAKD16	NAKD16V	CF6
KR19	KRV19	19	11	8	M8×1.25	10	12.2	32.2	20	0.6	0.3	0.25	300	210	20000	28	NAKD19	NAKD19V	CF8
KR22	KRV22	22	12	10	M10×1.25	12	13.2	36.2	23	0.6	0.3	0.3	410	320	17000	44	NAKD22	NAKD22V	CF10
KR26	KRV26	26	12	10	M10×1.25	12	13.2	36.2	23	0.6	0.3	0.3	410	320	17000	58	NAKD26	NAKD26V	CF10 - 1
KR30	KRV30	30	14	12	M12×1.5	13	15.2	40.2	25	6	0.6	0.6	590	450	14000	87	NAKD30	NAKD30V	CF12
KR32	KRV32	32	14	12	M12×1.5	13	15.2	40.2	25	6	0.6	0.6	0.3	590	450	14000	90	NAKD32	NAKD32V	CF12 - 1
KR35	KRV35	35	18	16	M16×1.5	17	19.6	52.1	32.5	8	0.8	0.6	0.35	850	760	10000	169	NAKD35	NAKD35V	CF16
KR40	KRV40	40	20	18	M18×1.5	19	21.6	58.2	36.5	8	0.8	1	0.35	1180	1220	8500	247	NAKD40	NAKD40V	CF18
KR47	KRV47	47	24	20	M20×1.5	21	25.6	66.1	40.5	9	0.8	1	0.35	1630	1690	7000	386	NAKD47	NAKD47V	CF20
KR52	KRV52	52	24	20	M20×1.5	21	25.6	66.1	40.5	9	0.8	1	0.35	1630	1690	7000	461	NAKD52	NAKD52V	CF20 - 1
KR62	KRV62	62	29	24	M24×1.5	25	30.6	80.1	49.5	11	0.8	1	0.4	2160	2210	6500	790	NAKD62	NAKD62V	CF24
KR72	KRV72	72	29	24	M24×1.5	25	30.6	80.1	49.5	11	0.8	1	0.4	2160	2210	6500	1040	NAKD72	NAKD72V	CF24 - 1
KR80	KRV80	80	35	30	M30×1.5	32	37	100	63	15	1	1	0.5	2830	3700	5000	1550	NAKD80	NAKD80V	CF30
KR85	KRV85	85	35	30	M30×1.5	32	37	100	63	15	1	1	0.5	2830	3700	5000	1740	NAKD85	NAKD85V	CF30 - 1
KR90	KRV90	90	35	30	M30×1.5	32	37	100	63	15	1	1	0.5	2830	3700	5000	1950	NAKD90	NAKD90V	CF30 - 2
